19" 1U PC Patch Panel 24-Port/s, Cat. 6A, gray, empty

Article no.: R813485
EAN / GTIN: 7611821040187
Delivery Unit: 1
Unit of Measure: PC

With a capacity for 24 connection modules Special with Category 6AISO, Category 6A EL and Category 8.1, shielded.



Scope of supply

  • 19" 1U 24-port patch panel, empty

  • 19" mounting kit

  • 4 labeling strips

  • Installation instructions

Technical Data
Protection class IP IP 20
PoE Yes
Amount of height units 1 U
Rack mounting version sub-rack
Assembly empty
Holder for connector / module Special (without mounting plate)
Capacity (ports) 24
Fastening 19 "
Mechanical Data
Dimensions 482.6 mm x 43.65 mm x 83.4 mm / 19 in x 1.719 in x 3.283 in (W x H x D)
Color front, medium gray (NCS 2502-B) / steel, blue, chromatized
Material plastic: PC, fiber-glass reinforced / steel: DC01 (1.0330), 1.5 mm
Electrical Data
Standard UL Listed

Modular patch panel with integrated cable tie shelf, integrated grounding system, 19" fastening kit, labeling fields with exchangeable labeling strips. The ports are prepared for a visual color coding system andautomated infrastructure management systems. Panel polycarbonate, fiber-glass-reinforced, halogen-free material, UL 94 listed and steel: DC01 (1.0330), 1.5 mm.

Color front: medium gray (NCS 2502-B) / steel: blue, chromatized.

With a capacity of upto 24 shielded RJ45 connection modules of Category 6A, Class EA for the establishing of transmission channelswith up to 4 plugged connections.
